One Kit containing 1x Housing + 2x Contact. Available in Red, Gray and Blue
SB 120 Amp Heavy Duty Anderson Connector
COLOR CODING
Housing is color coded and color coding can be used to indicate voltage. The housing and contacts are UL rated for 120 Amp and 600 Volts. The color is only to be used as an indicator, if needed.
For example RED connector connects only with other RED connector. This makes it impossible to connect to unwanted voltages.
These are the voltages to indicate with color:
24 Volt = Red
36 Volt = Grey
48 Volt = Blue
Recommended for use with AWG 2, 4, 6 and fits also 8 gauge wire sizes to perfect fit. Can be crimped or soldered and pressed with standard pressing tools for DIY use. Professional installations, please pick a crimp tool from our crimping tool section.
DescriptionA "Kit" is (1) colored housing, and (2) contacts.
Features
- Flat wiping contact system
- Interchangeable Genderless design
- Colored, Modular housings
- Polarized housings
- UL94 V-0 housing material
FEATURES
• Molded Side Grooves Allows for a secure panel mounting fit
• Mechanical Keyed Housings Prevents accidental mating of components operating at different voltage levels
• Single-piece Housing and Unitized Construction Provides industrial quality and durability
Benefits
- Allows for minimal contact resistance at high current, wiping action cleans contact surface during disconnection.
- Simplifies assembly requirements and reduces parts inventory.
- Allows customized multi-pole configurations with visual color coding to match wires.
- Prevents damage to connectors from being mated incorrectly.
- Allows versatility to choose product best suited to design requirements.
- Provides security in knowledge that the connector chosen meets strict UL flammability ratings.
