350A SB Battery Connectors

Original Anderson Power Products SB350 Series Heavy Duty Power Connector APP 350 Connectors from stock. These high-quality, original Anderson Power Products connectors are available in Yellow (12V), Orange (18V), Red (24V), Gray (36V), Blue (48V), and Green (72V) housing colors. Colors are for coding the voltage in use if you want to indicate the used voltage to avoid connecting with other voltages used on the same application or site. Important! All housings are UL-approved and tested for up to 600V and 350 Amp. Recommended for use with AWG 4/0, 3/0, 2/0, or 1/0 gauge wire. Kit includes the housing and two contacts - all needed for a single connector. Please note: All our connectors are 100% Genuine, Original Anderson Power Products. Manufactured within 18 months, so all silver finish on contacts are bright and clear. Using European wires? No problem! These fit well with users with the metric system wires (cable) as follows: AWG & GA 1/0 = 50mm2 wire/cable perfect fitAWG & GA 2/0 = 70mm2 wire/cable perfect fitAWG & GA 3/0 = 95mm2 wire/cable perfect fitAWG & GA 4/0 = 120mm2 wire/cable perfect fit We also have original reducing bushings available if you need to go down from AWG 1/0 to AWG 4 for example, which is the wire commonly used in low power chargers for example.

Read more less

Anderson SB350 -series contacts - Bulk Packed -version = most common way to pack these contacts. Select Wire diameter below: SB 350 Contacts are available as follows:917-BK = AWG 1/0 (also for 50mm2) [MPN: 917]907-BK = AWG 2/0 (also for 70mm2) [MPN: 907]916-BK = AWG 3/0 (also for 95mm2) [MPN: 916]908-BK = AWG 4/0 (also for 120mm) [MPN: 908] The Anderson SB350 series offers a range of high-quality contacts designed for superior electrical connectivity in various applications. This series includes four distinct models, each catering to different wire sizes for optimal compatibility and performance. Product Lineup Model: 917-BK Wire Size: AWG 1/0 (also suitable for 50mm²) MPN: 917 Description: Ideal for moderate power applications, the 917-BK offers reliable connections for AWG 1/0 wires. Its design ensures a secure fit and consistent conductivity. Model: 907-BK Wire Size: AWG 2/0 (also suitable for 70mm²) MPN: 907 Description: The 907-BK is tailored for slightly larger wire sizes, ensuring a robust connection for AWG 2/0 wires. Its construction is designed for durability and efficient power transfer. Model: 916-BK Wire Size: AWG 3/0 (also suitable for 95mm²) MPN: 916 Description: For applications requiring a stronger connection, the 916-BK is the go-to choice. Compatible with AWG 3/0 wires, it provides a stable and secure electrical connection. Model: 908-BK Wire Size: AWG 4/0 (also suitable for 120mm²) MPN: 908 Description: The 908-BK is designed for the heaviest duty applications within the series. It supports AWG 4/0 wires, offering exceptional conductivity and reliability for high-power demands. The Anderson SB350 series contacts, while rated for UL 600V, have their power capacity (in terms of maximum current or amperage) determined by various factors, including the wire size they are designed to accommodate and the specific application environment. The SB®350 connector from Anderson Power Products is designed for high-power applications, supporting up to 500 amps with a 350 mcm wire. The connector's features include a genderless design, mechanical keys color-coded for easy identification, and options for both wire and busbar contacts. The housing is available in a standard PC or a chemical-resistant PBT/PC blend, enhancing durability and reliability. Additionally, the SB®350 offers silver-plated contacts for reduced electrical resistance, and it is suitable for a wide range of wire sizes, from 1/0 to 350 mcm. The product line also includes accessories like cable clamps, handles, dust covers, lockout-tagout kits, and manual release brackets, catering to diverse application needs. 917-BK (AWG 1/0, 50mm²) Estimated Max Ampacity: For AWG 1/0 wire, the estimated maximum ampacity can range from 150 to 200 amps, depending on the insulation type and installation conditions.   907-BK (AWG 2/0, 70mm²) Estimated Max Ampacity: AWG 2/0 wire typically has a higher ampacity, potentially ranging from 175 to 300 amps.   916-BK (AWG 3/0, 95mm²) Estimated Max Ampacity: For AWG 3/0 wire, the maximum ampacity might range from 200 to 400 amps but please note the housing is only rated 350 amps.   908-BK (AWG 4/0, 120mm²) Estimated Max Ampacity: AWG 4/0 wire, being the largest in this series, can handle even higher currents, potentially up to 500 amps but please note the housing is only rated 350 amps. It's important to note that these figures are approximations and can vary based on the specific use case, environmental factors (like temperature), and the type of insulation used on the wires. For precise and safe application, it's recommended to consult the datasheets provided by Anderson Power Products or contact their technical support for detailed specifications. Additionally, always ensure that the entire electrical system, including connectors, wires, and protective devices, is rated appropriately for the intended voltage and current levels.

Read more less

350A contact for Anderson SB350 and fits REMA SR350 too.Made by Anderson Power Products. Might or might not have some "color wear" of longer stock time ( silver finish will turn darker when stocked over 1-2 years....). Our stocks does have multiple locations and multiple stock locations inside a warehouse so we always have this "old-stock" also available. Brush it clear quickly or use it as is. The contact surfaces will automatically self-clear when used so it is only a cosmetic issue. Professionals flush them bright or dip them in the clearing liquid. Makes no difference on the wear if not flushed. Looking for the best quality and factory new: You can find bulk-packed Anderson SB 350 contacts here. We so supply all sizes and do stock 1/0, 2/0, 3/0 and 4/0 -versions of Anderson SB 350 Heavy duty connector spare contacts. *Important Genuine or original Anderson SB350 contacts, known for their reliability and performance. These contacts are designed for heavy-duty applications, ensuring durability and safety. When looking for cheaper options, it's crucial to buy from reputable suppliers to avoid counterfeit products that might compromise quality and safety. Genuine contacts maintain high standards in electrical conductivity and physical strength, crucial for applications requiring high current capacity and durability. Always verify the authenticity and specifications to ensure you are getting the true Anderson quality. OEM NORDIC only supplies original Anderson Power Products (also known as APP).

Read more less

You can find bulk-packed Anderson SB 350 contacts here.

Read more less

You can find bulk packed Anderson SB 350 contacts here.

Read more less

You can find bulk-packed Anderson SB 350 contacts here.

Read more less

You can find bulk packed Anderson SB 350 contacts here.

Read more less

You can find bulk-packed Anderson SB 350 contacts here.

Read more less

Single contact for REMA SR 350. REMA SR 350 and Anderson SB 350 contacts (and housigns) are same form and same spec, therefore this contact will work with SB 350 housing also. DIY and repairs, workshop chargers you can use mixed, but for industrial applications and newbuilds: recommended to use with matching brand in first place.

Read more less

SR 350 - Product information A 350 AMP FLAT BLADE CONTACT CONNECTOR SR350 SERIESThis series is 100% compatible with Anderson SB350 series connectors and housings and vice versa. REMA is the European version of this legendary connector series seen all over the EV machines such as scissor lifts. Also used in fixed installation, such as 48V UPS stations, telecommunication junction boxes and battery systems. SR350 FLAT BLADE CONTACT BATTERY CONNECTOR Product features and advantages Reliable power connection solution for Electric vehicle batteries Battery chargers Forklift trucks Other DC voltage applications Operating voltage determined by housing colour simplifies mating of same voltages and protects from mating to unwanted voltages Genderless design Plug and socket with identical housing design reduces the quantity of components Acid resistant housing material Handels and strain relieve available CE Marking & UL recognized Contacts are sized for AWG (American Wire Gauge). REMA developed high-grade contacts made out of pure high conductive Cu-ETP copper with silver plated surface and an anti-friction and tarnish coating ensure power transition with minimal losses long life suitable for crimping REMA® SR350 Connector system is designed for optimum performance when used with 4/0 AWG cross section cable. The rated operating current is 350 A. Depending on the cross section and the laying procedure, the current rating is changed. The REMA SR 350 Connector is 100% interchangeable and mates with Anderson SB 350 Connectors.

Read more less

Anderson Power Products SB350 Powerpole Housings in many colors.100% original product

Read more less
