Single Auxiliary contact (1pcs) for REMA 160A socket version = female housing type.
Normally you need usually a pair (two pieces) for one connector.REMA catalog codes:Old code: 77640-00New code: 102714
This auxiliary contact fits MRC 320, MRC 400/ DIN 640 socket/female/feminine/dose
Auxiliary contact for signal bypassing
1.5 mm² connection cross-section
Material: Electrolytic copper Cu-ETP in accordance with EN 13601
Silver-plated surface for ultimate connection
High electrical conductivity
Can be used with socket type REMA DIN MRC 320/400 and DIN 640 Ampere battery connectors. *MRC 400 is MRC 320 connector equipped with the RED coding pin mpn 109632
Same as 120748 which is the updated version of 103747
120748 will work as 103747 but the borehole on 120748 has more depth and therefore the insulation must be cut accordingly to solder the cable and contact.
Pilot Contact set for REMA 160A Socket = Female, including 2 auxiliary contacts and holder/adapter (+plastic screw to tighten the leads in the middle of the cable clamp on the connector.)
REMA 160A Plug = Male, EURO BATTERY Battery Connector Pilot contact set including 2 auxiliary contacts, plastic adapter part and screw to hold the lead wires in the middle of the cable clamp.
Pilot contact set for DIN 160 / MRC 160 plugs (fits both of these, MRC is the one with connector molded to the cable at the factory, DIN is the standard with crimp/solder contacts you can mount to any cable)
REMA 108610 (old catalog code 75070-03, 75070/03 printed on the zip bag) is including the following items: 2 pilot contacts 102640, 1 pilot adapter 100030 with plastic screw
Set including Plastic adapter and 2 auxiliary (pilot) contacts. This set fits both DIN 320 and DIN 640 -series REMA Battery Connectors (socket/female/battery-side)
Genuine REMA -product108749 / 7559100 DIN 320 A pilot cont. set socketNew REMA catalog code 108749Old REMA catalog code 75591-00 (also 7559100 and 75591/00)
Pilot contact set for 320A plug Battery Connector from REMA
REMA old catalog code 75596-00REMA new code 108751
Pilot contact set includes
2x contact pins, auxilary contacts1x plastic adapter1x plastic screw to tighten the cable to cable stress clamp
111208 = REMA 108747 / 7559002 = DIN 320 / DIN 640 auxiliary contact for socket (1pc)
111208 REMA DIN 320 Auxilary (and Pilot w/ adapter) 320A Socket (1 pcs), metal part
120748 is the updated version of the old REMA catalog code 103747 / M9372071
Updated 120748 will work as 103747, but the borehole on 120748 has more depth and therefore the insulation must be cut accordingly to solder the cable and contact.
This is the updated version is this 120748
NEW version of the aux contact!
121556 is the version without any lead, lead-free brass with silver finish
120748 is the sunset version of this 121556, old REMA catalog code was 103747 / M9372071
Sunset 120748 will work as 103747, but the borehole on 120748 has more depth and therefore the insulation must be cut accordingly to solder the cable and contact. This updated 121556 is same as 120748, but has no lead in the brass of the contact.This is lead-free brass with silver finish.
Albright SW80 Series Contact Kit (2070-57)
The Albright SW80 Series Contact Kit (2070-57) is a high-quality replacement kit designed for use with the Albright SW80 SPST solenoid series. This contact kit includes all the essential components needed for maintaining or refurbishing the solenoid, ensuring peak performance and long-term reliability.
Key Features:
Complete Kit: Includes one moving contact (2070-13) and two contact studs with nuts and washers (2070-46), providing all parts required for contact replacement.
Genuine Albright Components: Manufactured to Albright’s exacting standards for maximum durability and electrical performance.
Easy Installation: Designed to fit seamlessly with the SW80 series, ensuring hassle-free replacement and minimizing downtime.
Restores Solenoid Functionality: Regular maintenance with genuine kits like the 2070-57 helps prolong the life of your equipment by restoring solenoid efficiency and reliability.
Applications:
Ideal for use in electrical systems requiring frequent contact maintenance, including forklifts, electric vehicles, and industrial equipment.
Why Choose Albright SW80 Series Contact Kit?
Albright products are trusted for their reliability and are engineered for demanding industrial and automotive environments, ensuring that your solenoids perform optimally with minimal maintenance.
1 contact stud, with nuts and washers. With silver alloy contact tips which are weld resistant, hard-wearing and have excellent conductivity.
Contents 1 x 2155-19 fixed contact.
Country of origin: United Kingdom / Lithuania (depends on manufacture week)Guarantee period: 24 months or 4000 hours of operation, from the date of manufacture of the product. - RMA procedure applies and all faulty products will be replaced without any extra cost.
Product/production Certificates: UL, CCC, ISO 9001, ISO 14001 All Albright Products Follow Reach, RoHS and Conflict Minerals
Albright SW200 series contact kit (all contacts)
One moving contact and two contact studs, with nuts and washers. With silver alloy contact tips which are weld resistant, hard-wearing and have excellent conductivity.
Kit code: 2155-99 / 2199-099
One contact kit repairs: 1 standard SW200 or SW200N solenoid contact.
Contents:1 x 2155-23 moving contact (including also 2155-7)2 x 2155-19 fixed contact.
Manufacturer: Albright Country of origin: United Kingdom / Lithuania (depends on manufacture week) Guarantee period: 24 months or 4000 hours of operation, from the date of manufacture of the product. - RMA procedure applies and all faulty products will be replaced without any extra cost. Product/production Certificates: UL, CCC, ISO 9001, ISO 14001 All Albright Products Follow Reach, RoHS and Conflict Minerals Product Weight: 0.24 kg per set
108687 / 7531500 DIN 80 A main contact 25 mm2 for plug (1 pc.)
** please note product mage shown is 16mm2 version. We are updating 25mm2 image the soonest.
The 95601-05 | REMA DIN 320 Socket with 50mm² Contacts + Handle is a high-quality, robust connector system designed for use in industrial and heavy-duty applications where reliable and secure power connections are essential. This socket is part of the REMA DIN 320 series, which is well-regarded for its durability, ease of use, and safety features.
Key Features:
50mm² Contacts: The socket comes equipped with 50mm² contacts, ensuring excellent conductivity and minimal power loss. This makes it suitable for high-current applications where efficiency and reliability are critical.
DIN 320 Standard: As part of the DIN 320 series, this socket complies with the DIN standards for industrial connectors, guaranteeing compatibility with other standardized equipment and ensuring safety and reliability in demanding environments.
Ergonomic Handle: The included handle enhances the usability of the socket, making it easier to connect and disconnect even in challenging conditions. The ergonomic design reduces strain on the user, allowing for safer and more efficient operation.
Durable Construction: Designed for industrial use, the REMA DIN 320 socket is built to withstand harsh conditions, including exposure to dust, moisture, and mechanical stress. Its robust construction ensures a long service life, even in the most demanding environments.
Secure Connection: The socket provides a secure and stable connection, reducing the risk of accidental disconnection or electrical faults. This reliability is crucial in applications where consistent power delivery is necessary.
Applications:
The 95601-05 REMA DIN 320 Socket is widely used in various industries due to its robust design and reliable performance. Typical applications include:
Material Handling Equipment: Ideal for use in forklifts, pallet jacks, and other material handling devices that require reliable power connections.
Industrial Machinery: Suitable for connecting power in heavy-duty industrial machinery, ensuring consistent and safe operation.
Electric Vehicles: Commonly used in electric vehicles (EVs) and related charging infrastructure where secure, high-current connections are required.
Renewable Energy Systems: Used in solar and wind energy systems to ensure efficient power transfer.
