Converter for charging a 12V lead-accumulator within a 24V car line 26(35)A-▪ IN: 24V / OUT: 12V ▪ Connection: open... Read more
€0,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Converter for charging a 12V lead-accumulator within a 24V car line 26(35)A-
▪ IN: 24V / OUT: 12V
▪ Connection: open cable end
| Input voltage: | 16 ... 30V DC |
| Output voltage: | half input voltage at input >26.4V |
| Output current: | 26A permanent, 35A for about 5 min. |
| Connection: | 3-pole plug "Anderson Powerpole Modular" |
| Power-on-voltage: | 26.4V |
| Power-off-voltage: | 25.0V |
| Cable length: | app. 180mm |
| Current without load: | 0.7mA at 24V |
| Efficiency: | app. 92% |
| Temperature range: | -40 ... +75°C, derating T>45°C |
| Electrical protection: | overcurrent, overtemperature, input transients |
| Mechanical protection: | entirely sealed |
| Dimensions: | 200 x 70 x 40mm |
| Mass: | app. 930g |
| Time-delay: | app. 5 sec. |
