Name: Converter "Mobil-Netz" Sw 600A-12
Brand: Briechle Elektronik
SKU: 130-10067
Price: 1157.0 EUR

Converter "Mobil-Netz" Sw 600A-12

Briechle Elektronik
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Converter "Mobil-Netz" Sw 600A-12

Briechle Elektronik
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Professional inverter 12V to 230V AC for rough environmental conditions.▪ IN: 12V / OUT: 230V/50Hz▪ Input: 2x open cable ends▪ Output:... Read more

€1.157,00 Excl. VAT

Guaranteed secure & safe checkout.

Free shipping on all orders above 115 USD / 100 EUR / 165 AUD / 85 GBP

30 days hassle-free returns

Flexible payments

Easily pay with multiple payment options.
Read more

Description

Professional inverter 12V to 230V AC for rough environmental conditions.

▪ IN: 12V / OUT: 230V/50Hz
▪ Input: 2x open cable ends
▪ Output: open cable ends

Weight: 8 kg

waterproof
starts automatically, 5mA standby
perfectly suitable for fixed installation in service vehicle, separate socket
100% overload possible
Attention: no sinus, but almost all consumers can be connected

Input voltage:	10 ... 15V DC
Output voltage:	225V +3% / -5%, 50Hz quartz-generated (115V/ 60Hz optional)
Output power:	600VA permanent, 1,200VA 10min, 12A (24A at 115V) 4sec
Connection input:	2x open cable end
Connection output:	open cable end
Cable length input:	2x app. 1200mm
Cable length output:	app. 2300mm
Current without load:	standby current 5mA RMS at 12V
Switching level:	start at 1W load
Current at 1W load:	1A at 12V
Overvoltage:	>16V, self-resetting
Undervoltage:	off at 10V, on at 11V
Efficiency:	app. 95% at 100% load / app. 80% at 10% load / app. 80% at 200% load
Electrical protection:	against reverse polarity, overtemperature, short circuit
Mechanical protection:	aluminum casting case IP66
Dimensions:	260 x 160 x 90mm (without screwings) without cable outlet
Mass:	app. 8,000g incl. Cables
Signalform:	step weave with fast PWM-modulation (to cos phi 0.2 at 50% load)
Safety:	potential division with potential compensation (protective conductor)

Specifications

Manuafacturer: Briechle Elektronik
Condition: New
