Professional inverter 24V to 230V AC for rough environmental conditions. ▪ IN: 24V / OUT: 230V/50Hz▪ Input: 2x open cable ends▪... Read more
€1.157,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Professional inverter 24V to 230V AC for rough environmental conditions.
▪ IN: 24V / OUT: 230V/50Hz
▪ Input: 2x open cable ends
▪ Output: open cable ends
| Input voltage: | 20 ... 30V DC |
| Output voltage: | 225V +3% / -5%, 50Hz quartz generated (115V/ 60Hz optional) |
| Output power: | 600VA permanent, 1,200VA 10min, 12A (24A at 115V) 4sec |
| Connection input: | 2x open cable end |
| Connection output: | open cable end |
| Cable length input: | 2x app. 1200mm |
| Cable length output: | app. 2300mm |
| Current without load: | standby current 5mA RMS at 12V |
| Switching level: | start at 1W load |
| Current at 1W load: | 0.6A at 26V |
| Overvoltage: | >33V, self-resetting |
| Undervoltage: | off at 20V, on at 22V |
| Efficiency: | app. 95% at 100% load / app. 80% at 10% load / app. 80% at 200% load |
| Electrical protection: | against reverse polarity, overtemperature, short circuit |
| Mechanical protection: | aluminum casting case |
| Dimensions: | 260 x 160 x 90mm (without screwings) without cable outlet |
| Mass: | app. 8,000g incl. Cables |
| Signalform: | step weave with fast PWM-modulation (to cos phi 0.2 at 50% load) |
| Safety: | potential division with potential compensation (protective conductor) |
