Special converter for the supply of a 24V anti-lock system ABS/EBS out of 12V or 24V. The converter input is... Read more
€319,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Special converter for the supply of a 24V anti-lock system ABS/EBS out of 12V or 24V.
The converter input is equipped with bare sheathed cable ending and the
output with a 24V ABS/EBS socket. Normal case: farming tractor from the distribution box. The contacts 6 and 7 ("CAN-Bus") are unequipped.
▪ IN: 12V ... 24V / OUT: 24V
▪ Input: bare cable
▪ Output: 24V socket
| Input voltage: | 9 ... 33V DC both lines |
| Output voltage: | 27V +-5% (27 ... 32V if input above 27V) |
| Output current line (term. 30): | 0 ... 10A (15A /20% on time cycle) |
| Output current line (term. 15): | 0 ... 500mA |
| Connection input: | bare sheathed cable |
| Connection output: | ABS / EBS socket 24V ISO'7638 |
| Cable length input: | app. 3000mm |
| Cable length output: | app. 500mm |
| Efficiency: | app. 80% |
| Electrical protection: | _ |
| Mechanical protection: | entirely sealed |
| Dimensions: | 200 x 70 x 40mm without cable outlet |
| Mass: | app. 1900g |
