Special converter for the supply of a 24V anti-lock system ABS/EBS out of 12V or 24V. The converter input is... Read more
€381,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Special converter for the supply of a 24V anti-lock system ABS/EBS out of 12V or 24V. The converter input is equipped with a 12V ABS/EBS plug and the output with a 24V ABS/EBS socket. The converter is mounted in a stainless steel rack with a parking socket and is ready for use. Normal case: truck side mounting. The contacts 6 and 7 ("CAN-Bus") are unequipped.
▪ IN: 12V ... 24V / OUT: 24V
▪ Input: 12V plug
▪ Output: 24V socket
▪ in stainless steel rack
| Input voltage: | 9 ... 33V DC both lines |
| Output voltage: | 27V +-5% (27 ... 32V if input above 27V) |
| Output current line (term. 30): | 0 ... 10A (15A /20% on time cycle) |
| Output current line (term. 15): | 0 ... 500mA |
| Connection input: | ABS / EBS plug 12V ISO'7638 |
| Connection output: | ABS / EBS socket 24V ISO'7638 |
| Cable length input: | app. 370mm |
| Cable length output: | _ |
| Efficiency: | ca. 80% |
| Mechanical protection: | entirely sealed and stainless steel rack |
| Dimensions: | 300 x 150 x 87mm + socket 45mm |
| Mass: | app. 3300g |
