Description
12 Volt resistor replacement load for the adaptation of light-emitting
diode (LED) trailer lamps at vehicles with incandescent lamp monitoring.
The direction indicator lamps and the contacts 9 to 13 are looped.
LED-ADAPT must be mounted on a metal surface. Important: The direction
indicators must be incandescent lamps or LEDs with their own monitoring. Other
lines may have additional load of 10W maximum, in this case monitoring
is disabled.
▪ Operating voltage: 12V
▪ Input: 12V 13-pol plug
▪ Output: 12V 13-pol socket
- Ready for use solution with 13 pin standard connectors
- Configuration: "2 incandescent lamps + 5 LED + contacts 9 to 13"
- No cabling work needed
- The additional pins 9 to 13 are looped
- Retrofitting for a factory finished trailer in case of incompatibility with a new vehicle
- Failure of an LED is detected (if no incandescent lamp is connected in parallel)
| Operation
voltage: |
12V nominal |
| Output current: |
0.8A (Over current protection time delay 1...2000s !) |
| Connection input: |
Male connector 13-pin 12V ISO'11446 |
| Connection output: |
Female socket with flap cover 13 pin 12V ISO'11446 |
| Load imitation: |
2x4W (rear lamps), 1x34W (stoplight) 1x17W (fog lamp), 1x17W
(reversing lamp) |
| Cable length input: |
app. 3300mm |
| Cable length output: |
app. 600mm |
| Temperature range: |
-40...+75°C |
| Electrical protection: |
Overcurrent, overtemperature, reverse polarity |
| Mechanical protection: |
entirely sealed |
| Dimensions: |
280 x 70 x 25mm without cable outlet |
| Mass: |
app. 2850g |
| Failure monitor LEDs: |
3mA (rear lamp) 8mA (stoplight) 8mA (fog lamp) 20mA
(reversing lamp) |
| Mounting rule: |
cooling plate 8dm² (aluminum
sheet 1.5mm thickness) or on chassis frame, lamp configuration only 2 x
incandescent lamps + 5xLED(+0...10W) |
