Description
DC-DC Converter Isolated 48 V to 24 V
This isolated DC-DC converter from Micropower Group is designed to convert a wide DC input range (33–65 V DC) into a stable 24 V DC output with high efficiency and robust performance. It uses advanced switching technology to achieve excellent efficiency, making it suitable for industrial, vehicle, and mobile power systems.
Key Specifications
-
Input Voltage: 33–65 V DC
-
Output Voltage: 24 V DC nominal (≈24.5 V)
-
Output Power: 200 W
-
Efficiency: >96 %
-
Isolation: Galvanically isolated
-
Ingress Protection: IP21 rated housing
-
Connections: 6.3 mm Fast-on terminals
-
Dimensions: 116 × 88 × 18 mm
-
Weight: ~0.2 kg
Main Features
-
Wide Input Range: Designed to work with 33–65 V DC sources for flexible use in various systems.
-
High Efficiency: Modern switching design reduces power loss and heat.
-
Galvanic Isolation: Provides electrical separation for safety and reduced noise.
-
Compact Industrial Design: Space-saving format for use in cabinets and mobile assemblies.
-
Built-in Protection: Internal safeguards against wrong polarity and short-circuit conditions.
Protection Functions
- Reverse polarity protection to help prevent installation damage.
- Short-circuit protection for enhanced reliability.
- Overload protection under excessive load conditions.
Typical Applications
- Industrial automation and control systems
- Mobile and vehicle power systems
- Battery-powered equipment
- Telecommunications power supplies
- Control panel power conversion
Installation & Integration
- Fast-on terminal connections for straightforward setup.
- Compact and lightweight design integrates easily in tight spaces.
- Reliable conversion for demanding industrial use.
Note: This isolated DC-DC converter delivers dependable 24 V DC power from a 48 V DC source with high efficiency and built-in protections — ideal for industrial, mobile, and vehicle applications.
