DC-DC Converter Isolated 9–36 V to 24 V (Wide Input)

This isolated DC-DC converter from Micropower Group is designed to convert a wide 9–36 V DC input into a reliable 24 V DC output with high efficiency and robust protection. This industrial converter offers low power loss and dependable electrical isolation, making it ideal for demanding applications in industrial systems and mobile equipment.

Key Specifications

• Input Voltage: 9–36 V DC
• Output Voltage: 24 V DC (nominal)
• Output Power: 200 W
• Efficiency: >96 %
• Isolation: Galvanically isolated
• Ingress Protection: IP21
• Connections: 6.3 mm Fast-on terminals
• Dimensions: 116 × 88 × 18 mm
• Weight: ~0.2 kg

Main Features

• Wide Input Compatibility: Accepts 9–36 V DC, giving flexibility in system design and power sources.
• High Efficiency: Designed with advanced switching technology for low loss and cool operation.
• Electrical Isolation: Provides galvanic isolation for improved electrical safety and noise immunity.
• Industrial Suitability: Compact and reliable design for continuous use in industrial environments.

• Protection: Built-in safeguards against wrong polarity and short-circuit conditions.


Typical Applications

• Industrial automation power supplies
• Vehicle and mobile systems
• Battery-powered equipment
• Telecommunications power units
• Control cabinet power distribution

Installation & Integration

• Fast-on terminal connections for easy installation
• Galvanic isolation suitable for noise-sensitive systems
• Compact design integrates into tight spaces in panels and cabinets

Specifications

• Manuafacturer: Micropower
• Condition: New
