Description
DC-DC Converter Non-Isolated 24 V to 12 V
This non-isolated DC-DC converter from Micropower Group is designed to convert a 24 V DC input into a stable 12 V DC output with high efficiency. It features modern switching technology for reliable, compact performance in industrial, automotive, and mobile applications.
Key Specifications
-
Input Voltage: 18–36 V DC
-
Output Voltage: 12.5 V nominal (≈13.7 V actual)
-
Output Power: 200 W
-
Efficiency: >96 %
-
Ingress Protection: IP21 standard enclosure
-
Connections: 6.3 mm Fast-on terminals
-
Dimensions: 116 × 88 × 18 mm
-
Weight: ~0.19 kg
Main Features
-
High Efficiency: Designed with advanced switching technology for minimal power loss and cool operation.
-
Non-Isolated Design: Direct step-down conversion where isolation is not required.
-
Compact & Lightweight: Small form factor ideal for constrained spaces.
-
Robust Protection: Internal safeguards including reverse polarity and short-circuit protection prevent damage from misuse.
Protection Functions
-
Reverse Polarity Protection: Prevents damage from incorrect connection.
-
Short-Circuit Protection: Enhances reliability under fault conditions.
-
Overload Protection: Safeguards the converter during high load conditions.
Typical Applications
- Industrial automation power supplies
- Vehicle and mobile power systems
- Battery-powered equipment
- Telecommunications and remote power units
- Control panels and machine power conversion
Installation & Integration
- Fast-on terminal connections for straightforward installation.
- Compact size integrates easily into panels and mobile systems.
- Designed for reliable performance in industrial environments.
Note: This non-isolated DC-DC converter provides efficient and dependable 12 V DC power from a 24 V DC source with high efficiency and built-in protections — suitable for a wide range of industrial and mobile applications.
