Description

REMA 95510-01 for DIN320 95mm² - Plug

Original REMA EURO DIN 320A / 95 mm² plug with grey coding, acid resistant 108960 / 9551001 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)

Original / Genuine REMA Euro DIN 320 amp battery connector plug set (male)

• Includes main contacts and housing, lock part, coding pin, cable clamp
• This is a Complete connector set
• Accessories are available, such as auxiliary contacts, pilot contact sets, handles, air pipes but are not included in the basic connector set.

Housing material – IMPORTANT CLARIFICATION

🔹 This is the Battery Acid Resistant, Dark Grey housing version

• Material: PP CoPo GF30 (copolymer polypropylene)

• Battery acid-resistant

• UL-tested version

• Recommended for demanding battery and traction applications

👉 Only the housing material differs between the black and dark grey versions. All electrical and mechanical connector parts are identical.

** As an alternative, a complete black housing version is available under part number 75510-01 which features a fully black housing made from shock-resistant polyamide (PA), offering increased mechanical strength and improved impact resistance.

Only the housing material is different between these two versions and to note the dark-grey version is the one the UL -tests are made with.

Specifications

• Manuafacturer: REMA
• Condition: New
