Description
This is the 640A Plug = Male version for charger / motor -side usually.
Select your wire diameter
(640A version contacts look a bit different from 320/160/80amp version)
You can be sure about the type by looking at the housing.
does not include a handle. ADD handle
Versions for a complete 640A plug=male=stecker connector with main contacts are:
70 mm2 REMA DIN 640 A Plug = 95850-30 = new code 111162
95 mm2 REMA DIN 640 A Plug = 95850-20 = new code 111161
120 mm2 REMA DIN 640 A Plug = 95850-10 = new code 111160
240 mm2 REMA DIN 640 A Plug = 95850-00 = new code 108995
The Original REMA DIN 640 battery connector system complements the product lines REMA DIN 80, 160, 320 with a high power battery connector at an unrivaled current rating of 640 amps. The connector system has been specifcally designed for the quick and opportunity charging of large battery capacities and corresponds to the DIN VDE 0632-589 and EN 1175-1.
POSSIBLE TO FIT 2 PAIRS OF AUXILARY CONTACTS
As special feature, it is possible to install an additional (second) pair of auxiliary contacts to the standard version with 1 pair of auxiliary and pilot contacts. The REMA devoloped contacts made out of pure high conductive Cu-ETP copper with silver plated surface and an anti-friction and tarnish coating ensure a power transition with minimal losses and a long life. The DIN 640 battery connector is suitable for a wide range of cable sizes. Cables from 70 mm² to 240 mm² can be crimped directly without using a reducing bushing. For best performance results and durability, the special developed REMA Crimp die sets and tools should be used.
Product features and advantages
REMA HIGH-POWER BATTERY CONNECTOR DIN 640 Complements the product lines REMA DIN 80, 160, 320 with a high power Battery Connector at an unrivaled current rating of 640 amperes Specifically designed for the quick and opportunity charging of large battery capacities Corresponds to the DIN VDE 0632-589 and EN 1175-1 Up to 2 pair of auxiliary contacts and 1 pair of pilot contacts can be equipped per connector High-grade contacts made out of pure high conductive Cu-ETP copper with silver plated sur-face and an anti-friction and tarnish coating ensure power transition with minimal losses long life Particularly preserved by acid-resistant construction Suitable for cable sizes from 70 mm² to 240 mm²
Direct crimping without reducing bushing for all cable sizes REMA die sets and tools provide best performance and durability. Please ask tools from our sales team.
