Special converter for the supply of a 12V anti-lock system out of 12V or 24V. Input and output cables are... Read more
€271,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Special converter for the supply of a 12V anti-lock system out of 12V or 24V. Input and output cables are cast solid, open-end.
▪ IN: 12V ... 24V / OUT: 12V
▪ Input: open cable end
▪ Output: open cable end
| Input voltage: | 9 ... 33V DC both lines |
| Output voltage: | 8,5 ... 12V +-5% |
| Output current line (term. 30): | 0 ... 6A (10A /20% on time cycle) |
| Output current line (term. 15): | 300mA |
| Connection input: | open cable end |
| Connection output: | open cable end |
| Cable length input: | app. 450mm |
| Cable length output: | app. 600mm |
| Efficiency: | app. 90% at 28V and nominal load, app. 96 ... 85% on term. 15, app. 92 ... 38% on term. 30 |
| Electrical protection: | Overload protection |
| Mechanical protection: | entirely sealed |
| Dimensions: | 170 x 70 x 25mm without cable outlet |
| Mass: | app. 800g |
