Step-up voltage converter with medium power from 12V until 24V (wide range) to 24V car line.▪ IN: 12V ... 24V /... Read more
€132,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Step-up voltage converter with medium power from 12V until 24V (wide range) to 24V car line.
▪ IN: 12V ... 24V / OUT: 24V
▪ Connection: 5-pol plug
▪ 5A Permanent positive
| Input voltage: | 8 ... 30V DC |
| Input current: | 11A at 13,0V (18A at 8,0V) at output current 5A |
| Output voltage: | 26V DC +-5% |
| Output current: | 5A permanent, 8A peak |
| Connection: | Connector Tyco Super Seal 1.5, 5-pol / 3 allocated, water protected IP67K |
| Cable length: | app. 100mm |
| Current without load: | 0.7mA at 12V |
| Efficiency: | app. 93% at 5A |
| Temperature range: | -40 ... +75°C, derating T>45°C |
| Electrical protection: | overcurrent, overtemperature, input transients, polarity |
| Mechanical protection: | entirely sealed |
| Dimensions: | 70 x 65 x 25mm without cable outlet |
| Mass: | app. 220g |
