Name: Albright SW60B-258 DC Contactor 80A 48V – Continuous Duty
Brand: Albright
SKU: 101-SW60B-258
Price: 29.9 EUR
Availability: InStock

Albright SW60B-258 DC Contactor 80A 48V – Continuous Duty

Albright
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Albright SW60B-258 DC Contactor 80A 48V – Continuous Duty

Albright
Share
- WhatsApp
- Deel
- X
- Pin it
- Messenger
- Email

Product form

Magnetic Blowouts These open case contactors are of double break configuration and are fitted with magnetic blowouts - denoted by 'B'... Read more

€29,90 Excl. VAT

Guaranteed secure & safe checkout.

Shipped today? Order within: Jun 05, 2026 12:00:00 +0300

Free shipping on all orders above 115 USD / 100 EUR / 165 AUD / 85 GBP

30 days hassle-free returns

Flexible payments

Easily pay with multiple payment options.
Read more

Description

Magnetic Blowouts

These open case contactors are of double break configuration and are fitted with magnetic blowouts - denoted by 'B' suffix in the SW60B range) across both contact gaps. These enable high currents to be ruptured very quickly so that arcing time is reduced to a minimum. Fitting of blowouts makes the contacts polarity sensitive and the positive markings on the top cover of the contactor must be observed.

About Continuous - CO.) SW60B Solenoids

Continuous contactors by design are predominantly used for drive functions on vehicles, they make and break slower than intermittent solenoids and are recommended for prolonged contact periods.
The SW60B features single pole double breaking main contacts with silver alloy tips, which are weld resistant, hardwearing and have excellent conductivity. The SW60B has M6 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or steel mounting brackets - supplied as separate items). Mounting can be on the side or base of the contactor.

Specifications

Manuafacturer: Albright
Condition: New
