Converter for the supply of a 24V trailer from a 12V or a 24V vehicle line, high-performance, also for LEDs.... Read more
€435,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
Converter for the supply of a 24V trailer from a 12V or a 24V vehicle line, high-performance, also for LEDs. For Mercedes Sprinter and Volkswagen Crafter the adaption module EC-ASV1 is required.
Important:
In the case of high loads and long cables on the input
side the current consumption could increase enormously determined by the
system. Please contact us, we provide planning aid and adaption
solutions.
▪ IN: 12V ... 24V / OUT: 24V
▪ Input: open cable end
▪ Output: open cable end
| Input voltage: | 12V...24V DC nominal (8 ... 30V) |
| Output voltage: | 26V + -5% |
| Output power: | 6 x 130W, total max. 450W |
| Connection input: | open cable end |
| Connection output: | open cable end |
| Cable length input: | app. 100cm |
| Cable length output: | app. 120cm |
| Current without load: | 0,5mA at open output |
| Efficiency: | about 92% |
| Temperature range: | -40 ... +75°C (load derating above 50° about 10W/°C |
| Electrical protection: | overload current (self-resetting) overtemperature (self-resetting) |
| Mechanical protection: | entirely sealed |
| Dimensions: | 280 x 75 x 25mm without cable outlet |
| Mass: | about 1,500g |
| Attention: | for bulbs and LEDs only! |
