Description
High-end voltage converter with medium power for 12V devices at 24V car
line. For the simultaneous supply of permanent plus and ignition plus.
▪ IN: 24V / OUT: 12V
▪ Connection: 5-pol plug
▪ 10A Permanent positive and ignition positive
Weight: 0.385 kg
- provides permanent plus (term. 30) and ignition plus (term. 15) up to the maximum load
- concept of high development standard:
- real voltage division, discharge protection of 12V device is effective
- significant low self current consumption of 0,7 mA
- very high efficiency of about 94%
- overload capacity up to 15A for about 5 min.
- small dimensions
- compact plug (AMP Mate Lock)
- 5kW-peak-safety-diode to prevent overvoltage from car line
| Input
voltage: |
16 ... 30V DC |
| Output voltage: |
8 ... 15V DC input voltage gets halved |
| Output current: |
10A permanent, 15A for about 5 min. |
| Connection: |
5-poles connector, round contacts (AMP Mate Lock) |
| Current without load: |
0,7mA at 24V |
| Efficiency: |
app. 94% |
| Temperature range: |
-40 ... +75°C, derating T>45°C |
| Electrical protection: |
overcurrent, overtemperature, input transients |
| Mechanical protection: |
entirely sealed |
| Dimensions: |
129 x 70 x 25mm incl. Plug |
| Mass: |
app. 385g |
| Technical principle: |
ignition plus (term 15) connects the second output |
