High-end voltage converter of a higher power for 12V consumers at a 24V car line. ▪ IN: 24V / OUT:... Read more
€242,00 Excl. VAT
Guaranteed secure & safe checkout.
Easily pay with multiple payment options.
Read more
High-end voltage converter of a higher power for 12V consumers at a 24V car line.
▪ IN: 24V / OUT: 12V
▪ Connection: 5-pol plug
▪ 26A Permanent positive and ignition positive
| Input voltage: | 16 ... 30V DC |
| Output voltage: | 8 ... 15V DC input voltage gets halved |
| Output current: | 26A permanent, 35A for about 5 min. |
| Connection: | 5-pole plug "Anderson Powerpole Modular" |
| Cable length: | app. 170mm |
| Current without load: | 0,7mA at 24V |
| Efficiency: | app. 92% |
| Temperature range: | -40 ... +75°C, derating T>45°C |
| Electrical protection: | overcurrent, overtemperature, input transients |
| Mechanical protection: | entirely sealed |
| Dimensions: | 200 x 70 x 40mm without cable outlet |
| Mass: | app. 960g |
| Technical principle: | ignition plus (term. 15) switches 2nd outlet |
