REMA 95515-01 for DIN320 50mm² - Plug with Aux.
Original REMA EURO DIN 320A / 50 mm² plug with grey coding, acid resistant 9551501
Includes main contacts and housing, lock part, coding pin, cable clamp + auxiliary contact pair (2 single aux contacs)
This is a Complete connector set
Battery Acid Resistant
Housing material – IMPORTANT CLARIFICATION
🔹 This is the Battery Acid Resistant, Dark Grey housing version
Material: PP CoPo GF30 (copolymer polypropylene)
Battery acid-resistant
UL-tested version
Recommended for demanding battery and traction applications
👉 Only the housing material differs between the black and dark grey versions. All electrical and mechanical connector parts are identical.
** As an alternative, a complete black housing version is available under part number 75515-01 which features a fully black housing made from shock-resistant polyamide (PA), offering increased mechanical strength and improved impact resistance.Only the housing material is different between these two versions and to note the dark-grey version is the one the UL -tests are made with.
REMA original main contact. Cooper inside, silver finish. FITS ONLY REMA Euro DIN Battery Connectors In 160A form Plug = Male = Stecker
Single 160A Plug contacts are available for the following wire sizes:
108585 / 7504810 DIN 160 A main contact 10 mm2 for plug (1 pc.)108583 / 7504801 DIN 160 A main contact 16 mm2 for plug (1 pc.)108587 / 7504901 DIN 160 A main contact 25 mm2 for plug (1 pc.)108589 / 7505001 DIN 160 A main contact 35 mm2 for plug (1 pc.)108591 / 7505101 DIN 160 A main contact 50 mm2 for plug (1 pc.)108592 / 7505105 DIN 160 A main contact 70 mm2 for plug (1 pc.)
* optionally you can do:16mm2 ( 25mm2 with reducing bushing 25-16 )10mm2 ( 25mm2 with reducing bushing 25-10 )108585 *Please message us on order or send us a message if you need 16 or 10mm2 direct contacts. You will normally get a slightly better crimp by using reducers with bigger contact having thicker crimp area.
REMA original main contact. Cooper inside, silver finish. FITS ONLY REMA Euro DIN Battery Connectors In 160A form Socket = Female = Dose
Single 160A Socket contacts are available for the following wire sizes:108543 7502101 DIN 160 A main contact 16 mm2 for socket (1 pc.)108544 7502201 DIN 160 A main contact 25 mm2 for socket (1 pc.)108546 7502301 DIN 160 A main contact 35 mm2 for socket (1 pc.)108548 7502401 DIN 160 A main contact 50 mm2 for socket (1 pc.)108549 7502405 DIN 160 A main contact 70 mm2 for socket (1 pc.)Options for small crimp areas:16mm2 ( Direct 16mm2 contact or 25mm2 with reducing bushing 25-16 )10mm2 ( Direct 10mm2 contact or 25mm2 with reducing bushing 25-10 )108543
* You will normally get a slightly better crimp by using reducers with bigger contact having thicker crimp area.
New Catalog no.
Old Catalog no.
Description
108739
7556001
DIN 320 A main contact 50 qmm for plug (1 pc.)
108743
7556501
DIN 320 A main contact 70 qmm for plug (1 pc.)
111105
7557001
DIN 320 A main contact 95 qmm for plug (1 pc.)
REMA DIN 320 spare contact (1pc) / single main contact: you need 2 pieces per one Socket.
New Catalog no.
Old Catalog no.
Description
108772
7566001
DIN 320 A main contact 50 qmm for socket (1 pc.)
108775
7566501
DIN 320 A main contact 70 qmm for socket (1 pc.)
108780
7567001
DIN 320 A main contact 95 qmm for socket (1 pc.)
REMA 640 Amp main contact for Socket = female
Sold as these versions:70mm2 (AWG 2/0)95mm2 (AWG 3/0)120mm2 (AWG 4/0)240mm2 (240 mm2 delivery time 2 work days)
FT80 Euro-standard Battery Connector Plug / Male 16mm2 + Aux. contacts
REMA FT 80 PLUG 16mm2 (AWG 6) + auxiliary contactsCatalog code: 81225-00
Includes housing, cable stress relief ( cable clamp), red coding pin, screws, Main Contacts ( 2 pcs ), 2x auxiliary contact
T-shaped Red Handle and Auxilary contacts are available as an accessory.
To ensure optimal electrical motor performance it is necessary to use only the most reliable and high quality connections. REMA FT Series connectors are the ones to guarantee long lasting connection with very low power loss. Design of these connectors is extremely compact and durable.
REMA FT80 connectors are in compliance with EN 1175-1
Service Voltages : 12, 24, 36, 48, 72, 80 V ( can be easily selected with the RED Colored pin included with connector )
The FT 80 A does not correspond to DIN Standard but it is in accordance with the Euro Standard.
Available accessories for FT80 series are : Main contacts ( spare ) , Auxiliary Contacts , Red Handle , Coding Pin , spare housing
To secure optimal output of electrical powered motors, not only a high power battery is necessart. Only with a reliable and high quality connection guarantees a long lasting connection without power losses.
WIth REMA FT80 you gain high amperage and small dimensions in one connector model. Each FT80 connection fulfils the highest quality standards and shows excellent functionality, robust reliability, easy handling and economy. These connectors are very inexpensive compared to what they offer.
The type FT 80 is in correspondence with French industrial standard and the European EN 1175-1 standard as well.REMA® FT80 battery / charger / motor connectors are suitable for use in the following applications:
Personnel / Burden Carriers
Golf Carts
Sweeper / Scrubber Floor Cleaning Equipment
Boats, Yachts & other marine vechicles
Light On-Highway Caravans,Trailer and Mobile Homes
REMA SR 175 series is european market alternative to Anderson SB 175. These connectors are equal quality and specs and fit together and can be mixed freely. 100% compatible. REMA connectors have over 70% market share in EU area.
Product features and advantages:
Reliable power connection solution for Electric vehicle batteries
Battery chargers Forklift trucksOther DC voltage applications
Operating voltage determined by housing color
Simplifies mating of same voltages
Plug and socket with identical housing design
Reduces quantity of components & Reduces purchasing and storage cost
Acid resistant housing material
Handels and strain relieves available
CE Marking & UL recognized Contacts sized for AWG (American Wire Gauge)
REMA developed high-grade contacts made out of pure high conductive Cu-ETP copper with silver plated surface and an anti-friction and tarnish coating ensure power transition with minimal losses long life suitable for crimping.
Single contact for REMA SR 350.
REMA SR 350 and Anderson SB 350 contacts (and housigns) are same form and same spec, therefore this contact will work with SB 350 housing also. DIY and repairs, workshop chargers you can use mixed, but for industrial applications and newbuilds: recommended to use with matching brand in first place.
SR 350 - Product information
A 350 AMP FLAT BLADE CONTACT CONNECTOR SR350 SERIESThis series is 100% compatible with Anderson SB350 series connectors and housings and vice versa. REMA is the European version of this legendary connector series seen all over the EV machines such as scissor lifts. Also used in fixed installation, such as 48V UPS stations, telecommunication junction boxes and battery systems.
SR350 FLAT BLADE CONTACT BATTERY CONNECTOR
Product features and advantages
Reliable power connection solution for
Electric vehicle batteries
Battery chargers
Forklift trucks
Other DC voltage applications
Operating voltage determined by housing colour simplifies mating of same voltages and protects from mating to unwanted voltages
Genderless design
Plug and socket with identical housing design reduces the quantity of components
Acid resistant housing material
Handels and strain relieve available
CE Marking & UL recognized
Contacts are sized for AWG (American Wire Gauge). REMA developed high-grade contacts made out of pure high conductive Cu-ETP copper with silver plated surface and an anti-friction and tarnish coating ensure power transition with minimal losses long life suitable for crimping
REMA® SR350 Connector system is designed for optimum performance when used with 4/0 AWG cross section cable. The rated operating current is 350 A. Depending on the cross section and the laying procedure, the current rating is changed. The REMA SR 350 Connector is 100% interchangeable and mates with Anderson SB 350 Connectors.
REMA SRE 320 multi-pole connectors feature a one-piece plastic housing and use stainless steel springs to hold low resistance contacts in place. All SRE 320 housings are chemical resistant and colour coded by the voltage to prevent mismatching of the power supply system.
RED will only connect with another REDBLUE will only connect with another BLUEand so on....
Metric contact sizes (50/7095mm2) does have short contact sleeveAmerican Wire Gauge contact size AWG 2/0 does have long contact sleeve
Rema Catalog Code
Type
Housing Color
Contacts Included
78340-00
SRE 320 complete
red
50 mm
78341-00
SRE 320 complete
red
70 mm
78342-00
SRE 320 complete
red
95 mm
78330-00
SRE 320 complete
grey
50 mm
78331-00
SRE 320 complete
grey
70 mm
78332-00
SRE 320 complete
grey
95 mm
78349-00
SRE 320 complete
black
50 mm
78350-00
SRE 320 complete
black
70 mm
78351-00
SRE 320 complete
black
95 mm
78335-00
SRE 320 complete
blue
50 mm
7833600
SRE 320 complete
blue
70 mm
78337-00
SRE 320 complete
blue
95 mm
78341-05
SRE 320 complete
red
AWG 2/0
78331-05
SRE 320 complete
grey
AWG 2/0
78350-05
SRE 320 complete
black
AWG 2/0
78336-05
SRE 320 complete
blue
AWG 2/0
REMA (Ameise Jungheinrich) Battery Plug A incl. Main contacts
max cable size 35mm2 = REMA 76250-00 = 160Amax cable size 50mm2 = REMA 76251-00 = 200A
Contacts can be crimped or soldered with cable.
These Twin plug and sockets by REMA are commonly used with truck and trailer connection.
Prior to standardization, REMA has developed these two poles electrical connection. These robust connectors have proofed their reliability already for decades. The focus of applications of these connectors are electrical connections between the trailer and towing machine on-road trucks. The contact design has large connection surfaces with a spring-loaded connector pin sliding into the sleeves inside the female connector. This results in extremely low resistance in the electrical connection. The contacts show a differentiation between solder and crimp connections.
On top the twin plug and sockets have:
mechanical robustness
constant extraction forces
protection against humidity, acids and UV radiation
reliable design for long lifetimes and vibration protection
The contacts are made from high-quality E-Cu copper, optimized for crimp connections. Crimp tooling and dies available on request from sales.
FITS ONTO VEHICLE SIDE of Trailer Connection
REMA Vehicle socket B incl. Main contacts.
These Twin plug and sockets by REMA are commonly used with truck and trailer connection.
Prior to standardization REMA has developed this two pole electrical connection. These robust connectors have proofed there reliability already for decades. Focus of applications of these connectors are electrical connections between trailer and towing machine on road trucks. The contact design has large connection surfaces with a spring loaded connector pin sliding into the sleeves inside the female connector. This results to extremely low resistance in the electrical connection.The contacts show a differentiation between solder and crimp connections.
On top the twin plug and sockets have:
mechanical robustness
constant extraction forces
protection against humidity, acids and UV radiation
reliable design for long lifetimes and vibration protection
The contacts are made from high quality E-Cu copper, optimized for crimp connections. Crimp tooling and dies available on request from sales.
