Battery Connector Accessories
-
REMA Rema Connector 75012-01 DIN 160 A - 35mm² - Socket with handle (black)
REMA 75012-01 Original REMA EURO DIN 160A / 35 mm² socket, grey coding, fixed handle 108527 / 7501201 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the total black housing -version[Nylon PA6-GF30 housing -version] The housing material is Nylon PA6 GF 30 which is high-impact resistant. Alternatively, you can select the dark grey housing version of this connector, which is PP CoPo GF 30 -material battery and better to resist battery acids and called the battery acid-proof. Only the housing material is different between these two versions and to note the dark-grey version is the one the UL -tests are made with.
€29,00
-
REMA Rema Connector 75017-01 DIN 160 A - 50mm² - Socket with handle (black)
REMA 75017-01 DIN 160 50mm2 with fixed handle Original REMA EURO DIN 160A / 50 mm² socket, grey coding, fixed handle 108536 / 7501701 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the total black housing -version[Nylon PA6-GF30 housing -version] The housing material is Nylon PA6 GF 30 which is high-impact resistant. Alternatively, you can select the dark grey housing version of this connector, which is PP CoPo GF 30 -material battery and better to resist battery acids and called the battery acid-proof. Only the housing material is different between these two versions and to note the dark-grey version is the one the UL -tests are made with.
€34,99 €27,00
-
REMA Rema Connector 75306-01 DIN 80 A - 16mm² - Socket with handle (black)
Original REMA EURO DIN 80A / 16 mm² socket, grey coding, fixed handle 108659 / 7530601 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA Rema Connector 75309-01 DIN 80 A - 35mm² - Socket with handle (black)
Original REMA EURO DIN 80A / 35 mm² socket, grey coding, fixed handle 108669 / 7530901 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA Rema Connector 75324-01 DIN 80 A - 25mm² - Socket with handle (black)
Original REMA EURO DIN 80A / 25 mm² socket, grey coding, fixed handle 108708 / 7534201 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA Rema Connector 95001-01 DIN 160 A - 16mm² - Socket with handle
REMA 95001-01 Original REMA EURO DIN 160A / 16 mm² socket, grey coding, fixed handle, acid resistant 108806 / 9500101 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the dark grey housing -version[PP CoPo GF 30 housing -version] The housing material is PP CoPo GF 30 which is highly battery acid resistant. Alternatively, you can select the black housing version of this connector, which is Nylon PA6-GF30 -material and has better impact resistance. Only the housing material is different between these two versions. Please note the dark-grey version (this one) is the one the UL -tests are made with but both versions have the same technical characteristics and they do interconnect 100%.
€36,00
-
REMA Rema Connector 95007-01 DIN 160 A - 25mm² - Socket with handle
REMA 95007-01 Original REMA EURO DIN 160A / 25 mm² socket, grey coding, fixed handle, acid resistant 108812 / 9500701 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the dark grey housing -version[PP CoPo GF 30 housing -version] The housing material is PP CoPo GF 30 which is highly battery acid resistant. Alternatively, you can select the black housing version of this connector, which is Nylon PA6-GF30 -material and has better impact resistance. Only the housing material is different between these two versions. Please note the dark-grey version (this one) is the one the UL -tests are made with but both versions have the same technical characteristics and they do interconnect 100%.
€29,00
-
REMA Rema Connector 95012-01 DIN 160 A - 35mm² - Socket with handle
REMA 95012-01 Original REMA EURO DIN 160A / 35 mm² socket, grey coding, fixed handle, acid resistant 108818 / 9501201 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the dark grey housing -version[PP CoPo GF 30 housing -version] The housing material is PP CoPo GF 30 which is highly battery acid resistant. Alternatively, you can select the black housing version of this connector, which is Nylon PA6-GF30 -material and has better impact resistance. Only the housing material is different between these two versions. Please note the dark-grey version (this one) is the one the UL -tests are made with but both versions have the same technical characteristics and they do interconnect 100%.
€29,00
-
REMA Rema Connector 95017-01 DIN 160 A - 50mm² - Socket with handle
REMA 95017-01 Original REMA EURO DIN 160A / 50 mm² socket, grey coding, fixed handle, acid resistant 108826 / 9501701 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the dark grey housing -version[PP CoPo GF 30 housing -version] The housing material is PP CoPo GF 30 which is highly battery acid resistant. Alternatively, you can select the black housing version of this connector, which is Nylon PA6-GF30 -material and has better impact resistance. Only the housing material is different between these two versions. Please note the dark-grey version (this one) is the one the UL -tests are made with but both versions have the same technical characteristics and they do interconnect 100%.
€29,00
-
REMA Rema Connector 95017-05 DIN 160 A - 70mm² - Socket with handle
REMA 95017-05 Original REMA EURO DIN 160A / 70 mm² socket, grey coding, fixed handle, acid resistant 108829 / 9501705 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr) Original / Genuine REMA Euro DIN 160 amp battery connector socket (female) with molded/fixed handle Includes main contacts and housing, lock part, coding pin, cable clamp This is a Complete connector set Quick delivery Low price This is the dark grey housing -version[PP CoPo GF 30 housing -version] The housing material is PP CoPo GF 30 which is highly battery acid resistant. Alternatively, you can select the black housing version of this connector, which is Nylon PA6-GF30 -material and has better impact resistance. Only the housing material is different between these two versions. Please note the dark-grey version (this one) is the one the UL -tests are made with but both versions have the same technical characteristics and they do interconnect 100%.
€29,00
-
REMA Rema Connector 95306-01 DIN 80 A - 16mm² - Socket with handle
Original REMA EURO DIN 80A / 16 mm² socket, grey coding, fixed handle, acid resistant 108914 / 9530601 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA Rema Connector 95309-01 DIN 80 A - 35mm² - Socket with handle
Original REMA EURO DIN 80A / 35 mm² socket, grey coding, fixed handle, acid resistant 108920 / 9530901 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA Rema Connector 95324-01 DIN 80 A - 25mm² - Socket with handle
Original REMA EURO DIN 80A / 25 mm² socket, grey coding, fixed handle, acid resistant 108935 / 9534201 are the REMA catalog numbers for the item indicated as (new catalog nr/old catalog nr)
€26,00
-
REMA REMA DIN 640 Plug High Power Battery Connector (Male, Charger / Motor Side)
This is the 640A Plug = Male version for charger / motor -side usually. Select your wire diameter (640A version contacts look a bit different from 320/160/80amp version)You can be sure about the type by looking at the housing. does not include a handle. ADD handle Versions for a complete 640A plug=male=stecker connector with main contacts are: 70 mm2 REMA DIN 640 A Plug = 95850-30 = new code 11116295 mm2 REMA DIN 640 A Plug = 95850-20 = new code 111161120 mm2 REMA DIN 640 A Plug = 95850-10 = new code 111160240 mm2 REMA DIN 640 A Plug = 95850-00 = new code 108995 The Original REMA DIN 640 battery connector system complements the product lines REMA DIN 80, 160, 320 with a high power battery connector at an unrivaled current rating of 640 amps. The connector system has been specifcally designed for the quick and opportunity charging of large battery capacities and corresponds to the DIN VDE 0632-589 and EN 1175-1. POSSIBLE TO FIT 2 PAIRS OF AUXILARY CONTACTSAs special feature, it is possible to install an additional (second) pair of auxiliary contacts to the standard version with 1 pair of auxiliary and pilot contacts. The REMA devoloped contacts made out of pure high conductive Cu-ETP copper with silver plated surface and an anti-friction and tarnish coating ensure a power transition with minimal losses and a long life. The DIN 640 battery connector is suitable for a wide range of cable sizes. Cables from 70 mm² to 240 mm² can be crimped directly without using a reducing bushing. For best performance results and durability, the special developed REMA Crimp die sets and tools should be used. Product features and advantagesREMA HIGH-POWER BATTERY CONNECTOR DIN 640 Complements the product lines REMA DIN 80, 160, 320 with a high power Battery Connector at an unrivaled current rating of 640 amperes Specifically designed for the quick and opportunity charging of large battery capacities Corresponds to the DIN VDE 0632-589 and EN 1175-1 Up to 2 pair of auxiliary contacts and 1 pair of pilot contacts can be equipped per connector High-grade contacts made out of pure high conductive Cu-ETP copper with silver plated sur-face and an anti-friction and tarnish coating ensure power transition with minimal losses long life Particularly preserved by acid-resistant construction Suitable for cable sizes from 70 mm² to 240 mm² Direct crimping without reducing bushing for all cable sizes REMA die sets and tools provide best performance and durability. Please ask tools from our sales team. Browse all REMA Connectors here
€189,99 - €199,99
-
REMA REMA DIN 80 Coding PIN
Fits REMA 80A EURO DIN black and dark grey housings. Both Socket and Plug uses this same coding pin for voltage coding Green, Yellow and Grey options below. Standard is Grey. REMA REMA (old code) Description 100072 75435-00 DIN 80 A coding pin grey (wet) 100075 75438-00 DIN 80 A coding pin green (dry) 100074 75436-00 DIN 80 A coding pin yellow (wet/ dry)
€3,50 €1,99
-
REMA REMA DIN320 / MRC320 handle grey. Bended, with 4 screws, acid resistant (MPN: 108880 / 95066-67)
Standard DIN Connector spare handle with slightly bent handle form. Battery acid proof handle, made of PolyPropylene. Includes screws for both 160A and 320A housing types.
€6,99 €5,49
-
REMA REMA FT80 Coding Pin, Red
100210 8123600
€3,50 €2,99
-
REMA REMA FT80 handle, red, T-shaped with screws
REMA FT80 handle, fits both PLUG and SOCKET. Includes 1x red T-shaped handle4x mount screw
€4,70
-
REMA REMA handle red SRX 175 & SRE 160 (MPN: 109403/7829134)
REMA handle, red, angled- 4 screws M6 x 36
€7,25
-
REMA REMA MRC260 Coding PIN Plug, for MRC 260 Ampere
Plug/Male red coding pin for 260A version (same physical side housing as REMA 160A MRC but coded as 260A)
€5,99
-
REMA REMA MRC260 Coding PIN Socket, for MRC 260 Ampere
Socket/Female red coding pin for 260A version (same physical side housing as REMA 160A MRC but coded as 260A)
€5,99
-
Anderson Power Products SB50 Handle
SB50-HDL-RED Fits Anderson SB50 and REMA SR50 and Many other brands also.
€4,95 €2,99
-
Anderson Power Products SBE 80 - 16 mm² - red - incl. screwed handle [MPN: SBE80RED16MMHDL]
€27,00
You have seen 95 out of 95 products
