Continuous contactors by design are predominantly used for drive functions on vehicles, they make and break slower than intermittent solenoids and are recommended for prolonged contact periods.
The SW80P features an enclosed top cover and offers environmental protection to IP66. The SW80P has M8 stud main terminals and 6.3mm spade coil connections. Mounted using supplied brackets, mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
Albright SW80-753PE
Also known and sold as SOLENOID 24V 80AMP HALDEX SW80-753PE
This is the original Albright made, genuine SW80-753PE Albright 24V INT Single Pole Single Throw Contactor. The SW80-753PE, a Albright SW80 -series contactor has been developed for direct current loads, including motors as used on different kind of electric vehicles like industrial trucks a
Albright SW80B-1648 Single-Acting Solenoid Contactor
Specifications:
• Voltage: 125V continuous • Mounting: Integral bracket fitted • Winding: Vacuum-impregnated • Insulation: Coil insulators fitted • Connections: 24-inch long flying leads coil connection
Features:
• Design: The SW80 series is designed for direct current loads, particularly for motors used in small electric vehicles like light industrial trucks and powered invalid cars. • Contacts: Equipped with double-breaking contacts with Silver-alloy contact tips, which are weld-resistant, hardwearing, and offer excellent conductivity. • Cost: Economically priced, they compare favorably with sealed automotive-style solenoid switches that cannot be serviced or inspected for contact wear. • Auxiliary Switch Kit: Part number 2070-124.
Dimensions:
• Height: 94mm (including terminals and coil base cap) • Coil Width: 41mm • Cap Width: 50.5mm • Cap Depth: 39mm
Magnetic Blowouts:
• These contactors have a double break configuration with magnetic blowouts (denoted by the ‘B’ suffix in the SW80 range) across both contact gaps. This allows for quick rupture of high currents, minimizing arcing time. Note that the blowouts make the contacts polarity sensitive, and the positive markings on the top cover must be observed.
Continuous contactors by design are predominantly used for drive functions on vehicles, they make and break slower than intermittent solenoids and are recommended for prolonged contact periods.
The SW80 has M8 stud main terminals and 6.3mm spade coil connections. Mounting is via the integral bracket formed into the coil housing case. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
Specifications
Device Type
NO - SP - ST
Voltage
125V D.C.
Coil Type
Continuous
Amps
100 Amps
Coil Resistance (Ohms)
1500
Pull-In Voltage (V)
75.0 Max.
Drop Out Voltage (V)
32.0 Max.
Coil Power Dissipation (W)
10.42
Typical Pull-In Time
20ms
Typical Voltage Drop Per PoleAcross New Contacts At 100A
40mV
Operating Ambient Temperature
-40 to +60℃
Weight
430g
Application
Interrupted
Uninterrupted
Thermal Current Rating
100A
125A
Intermittent Current Rating:
30% Duty
185A
230A
40% Duty
160A
200A
50% Duty
140A
175A
60% Duty
130A
160A
70% Duty
120A
150A
Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods.
The SW80 has M8 stud main terminals and 6.3mm spade coil connections. Mounting is via the integral bracket formed into the coil housing case.
Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
Genuine SW80B-6 Albright 24V Solenoid Switch. The SW80B-6, a Albright SW80 -series contactor with magnetic blowouts - B) fitted, has been developed for direct current loads, including motors as used on different kind of electric vehicles like industrial tr
Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods.
The SW80 has M8 stud main terminals and 6.3mm spade coil connections. Mounting is via the integral bracket formed into the coil housing case. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
About Intermittent - Int.) SW82-1 Solenoids Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods. The contactors are compact in size and are fully serviceable with a full range of spare parts available. The SW82 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or by purchasing mounting brackets. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
Genuine SW82-122P ALBRIGHT 28V 100A CO DC - COntactor. The SW82-122P, a Albright SW82 type of contactor has been designed for direct current loads, including motors as used on electric vehicles like industrial fork lift trucks and pallet movers. Developed f
Genuine SW82-122P ALBRIGHT 28V 100A CO DC - COntactor. The SW82-122P, a Albright SW82 type of contactor has been designed for direct current loads, including motors as used on electric vehicles like industrial fork lift trucks and pallet movers. Developed f
About Intermittent - Intermittent SW82-3 Solenoid
Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods. The contactors are compact in size and are fully serviceable with a full range of spare parts available. The SW82 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or by purchasing mounting brackets. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
About Continuous - CO.) SW82-4 Solenoids Continuous contactors by design are predominantly for drive functions on vehicles, they switch slower than intermittent solenoids and are recommended for prolonged contact periods. The contactors are compact in size and are fully serviceable with a full range of spare parts available. The SW82 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or by purchasing mounting brackets. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
About Intermittent - Int.) SW84-1 Solenoids Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods. The SW84 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or mounting brackets purchased as separate items. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards. Please note Normally Closed contacts are not suited to make and break load.
Albright SW84-466L 12V DC
The Albright SW84-466L 12V Pump Contactor is a robust and dependable choice for efficient pump control. Known for its superior pump control performance, this contactor ensures smooth, uninterrupted operation, boosting productivity while helping to lower energy expenses.
Also known with the following references:
Logitrans 982097 - The Logitrans Albright SW84-466L 12V Pump Contactor is compatible with the following machine: Logitrans EHL1004
SW84B-4 Albright
Magnetic Blowouts
These contactors are fitted with magnetic blowouts - denoted by 'B' suffix in the SW84B range) across contact gaps. These enable high currents to be ruptured very quickly so that arcing time is reduced to a minimum. Fitting of blowouts can make the contacts polarity sensitive and the positive markings on the top cover of the contactor must be observed.
About Continuous - CO.) SW84B-4 Solenoids
Continuous contactors by design are predominantly for drive functions on vehicles, they switch slower than intermittent solenoids and are recommended for prolonged contact periods.
The SW84 has M8 stud main terminals and 6.3mm spade coil connections. It can be mounted via M4 tapped holes or mounting brackets purchased as separate items. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards. Please note Normally Closed contacts are not suited to make and break load.
Reliable Single-Acting Solenoid Contactor
Albright SW80 100A or 125A, SPST, Normally Open, DC Contactor For High-Powerthis is the standard version and most common version of SW80 -type/series and is called just an "SW80"
Features
100 or 125A Continuous Duty Rating
Normally Open, SPST, DC Contactor
UL Recognized for Electric Vehicles (100A)
UL Recognized for Power Systems (125A)
In the realm of industrial automation and control systems, the demand for reliable and efficient components is paramount. The DC Contactor SW80 100A emerges as a standout solution, particularly for high-power applications requiring precise control and durability. This single-acting solenoid contactor is designed to deliver exceptional performance, ensuring seamless operation in various industrial settings.
Key Features and Specifications
The DC Contactor SW80L 100A is engineered with precision to meet the rigorous demands of industrial applications. Its key features and specifications include:
Voltage and Current Rating: This contactor operates at a nominal voltage of your selection from 6V to 96V DC, with a high current handling capacity of 100A, making it suitable for a wide range of applications that require high power switching.
Single-Acting Solenoid Mechanism: The single-acting solenoid design allows for reliable operation, with a straightforward engage and disengage mechanism. This simplicity ensures robust performance and reduces the potential for mechanical failures.
Durability: Constructed with high-quality materials, the SW80 contactor is built to withstand harsh industrial environments. It features excellent resistance to vibration, shock, and temperature variations, ensuring a long service life.
Compact Design: Despite its powerful capabilities, this contactor boasts a compact design, making it easy to integrate into existing systems without requiring significant space.
Versatility: The SW80 100A is versatile, and suitable for a variety of applications, including electric vehicles, material handling equipment, renewable energy systems, and industrial machinery. Its design ensures compatibility with a broad range of control systems.
Applications
The DC Contactor SW80 100A is particularly well-suited for applications where reliable high-power switching is crucial. These include:
Electric Vehicles (EVs): It can be used for controlling the main propulsion system, auxiliary systems, and charging circuits in electric vehicles.
Renewable Energy Systems: In solar and wind power installations, it serves to manage the flow of electricity from the generation source to the storage units or grid.
Material Handling: For equipment such as forklifts and conveyor systems, this contactor ensures efficient and safe power management.
Industrial Automation: It plays a critical role in the control systems of various machinery, providing the necessary power-switching capabilities for automated processes.
Conclusion
The DC Contactor SW80 100A is an essential component for industries looking for a reliable, high-performance single-acting solenoid contactor. Its robust design, combined with high power handling capacity and versatility, makes it a preferred choice for a wide range of applications. Whether it's for electric vehicles, renewable energy systems, material handling equipment, or industrial automation, this contactor ensures efficient, safe, and reliable operation, contributing to the overall performance and longevity of the system it is a part of.
Reliable Single-Acting Solenoid Contactor
Albright SW80L 100A or 125A, SPST, Normally Open, DC Contactor For High-Power with Extra Large Tips/Contact surfaces, therefore "L" is added to SW80
Features
100A Intermittent or 125A Continuous Duty Rating
Normally Open, SPST, DC Contactor
UL Recognized for Electric Vehicles (100A)
UL Recognized for Power Systems (125A)
Applications of SW80L
In the realm of industrial automation and control systems, the demand for reliable and efficient components is paramount. The DC Contactor SW80 100A emerges as a standout solution, particularly for high-power applications requiring precise control and durability. This single-acting solenoid contactor is designed to deliver exceptional performance, ensuring seamless operation in various industrial settings.
Key Features and Specifications
The DC Contactor SW80L 100A is engineered with precision to meet the rigorous demands of industrial applications. Its key features and specifications include:
Voltage and Current Rating: This contactor operates at a nominal voltage of your selection from 6V to 96V DC, with a high current handling capacity of 100A, making it suitable for a wide range of applications that require high power switching.
Single-Acting Solenoid Mechanism: The single-acting solenoid design allows for reliable operation, with a straightforward engage and disengage mechanism. This simplicity ensures robust performance and reduces the potential for mechanical failures.
Durability: Constructed with high-quality materials, the SW80 contactor is built to withstand harsh industrial environments. It features excellent resistance to vibration, shock, and temperature variations, ensuring a long service life.
Compact Design: Despite its powerful capabilities, this contactor boasts a compact design, making it easy to integrate into existing systems without requiring significant space.
Versatility: The SW80 100A is versatile, and suitable for a variety of applications, including electric vehicles, material handling equipment, renewable energy systems, and industrial machinery. Its design ensures compatibility with a broad range of control systems.
Applications
The DC Contactor SW80 100A is particularly well-suited for applications where reliable high-power switching is crucial. These include:
Electric Vehicles (EVs): It can be used for controlling the main propulsion system, auxiliary systems, and charging circuits in electric vehicles.
Renewable Energy Systems: In solar and wind power installations, it serves to manage the flow of electricity from the generation source to the storage units or grid.
Material Handling: For equipment such as forklifts and conveyor systems, this contactor ensures efficient and safe power management.
Industrial Automation: It plays a critical role in the control systems of various machinery, providing the necessary power-switching capabilities for automated processes.
Conclusion
The DC Contactor SW80 100A is an essential component for industries looking for a reliable, high-performance single-acting solenoid contactor. Its robust design, combined with high power handling capacity and versatility, makes it a preferred choice for a wide range of applications. Whether it's for electric vehicles, renewable energy systems, material handling equipment, or industrial automation, this contactor ensures efficient, safe, and reliable operation, contributing to the overall performance and longevity of the system it is a part of.
About the DC88-1 Motor Reversing Solenoid Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods. The main contact circuit, designed for motor reversing, has a built-in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuit. This version of the DC88 has M8 stud main terminals and 6.3mm spade coil connections. Mounting is via the integral bracket formed into the coil housing case. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
About the DC88-2 Motor Reversing Solenoid Continuous contactors by design are predominantly used for drive functions on vehicles, they make and break slower than intermittent solenoids and are recommended for prolonged contact periods. The main contact circuit, designed for motor reversing, has a built-in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuit. This version of the DC88 has M8 stud main terminals and 6.3mm spade coil connections. Mounting is via the integral bracket formed into the coil housing case. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
About the DC88-259 Motor Reversing Solenoid
The DC88-259 Albright 100A 12V DC - INT Monoblock Motor Reversing Contactor is a high-quality motor-reversing solenoid designed for intermittent use with direct current loads. Ideal for small electric vehicles and marine equipment, it features double-breaking main contacts with silver-alloy tips for excellent conductivity and durability. Its monoblock construction offers a compact design, with built-in fail-safe mechanisms for safety. This contactor is suitable for applications requiring quick make and break connections, and it is not recommended for prolonged contact periods.
"Bow & Stern -thruster solenoid contactor with flying leads connection"
This Albright 100A 12V DC - INT Monoblock Motor Reversing Contactor represents a pinnacle of design and engineering in the realm of motor-reversing solenoids.. It is specifically tailored for intermittent use across a wide array of direct current (DC) load applications. This product is a standout choice for operators and designers of small electric vehicles and marine equipment. DC88-series is your safe pick, providing a robust solution for the most demanding environments.
One of the hallmark features is its double-breaking main contacts equipped with silver-alloy tips. This choice of materials ensures superior electrical conductivity and exceptional durability. This enabling the contactor to handle high current loads with ease while offering a prolonged service life. The silver-alloy tips play a crucial role in minimizing contact resistance and enhancing performance under load.
The DC88-259 (DC88 259 revision) Monoblock Design
The monoblock construction of the DC88-259 contactor is another key attribute, emphasizing compactness and efficiency in design. This integrated construction approach not only saves space, making it ideal for applications where space is at a premium, but also contributes to the overall reliability and robustness of the device. The compact design does not compromise on functionality or safety, with built-in fail-safe mechanisms ensuring operation remains within safe parameters, protecting both the equipment and its users.
Designed for applications that necessitate quick make and break connections. This motor reversing contactor excels in scenarios where rapid switching is required, such as in control systems for electric vehicles or winching operations in marine environments. Its ability to swiftly connect and disconnect electrical circuits helps in reducing wear and tear on components - Thereby extending the lifespan of the overall system.
However, it's important to note that the coil is optimized for intermittent use and is not recommended for applications where contacts need to remain engaged for prolonged periods. This specification ensures that the contactor is used within its optimal performance range, safeguarding against potential overheating or damage that could occur in continuous duty applications.
In summary, the DC88-259 Albright 100A 12V DC - INT Monoblock Motor Reversing Contactor is a top-tier choice for professionals seeking reliable, efficient, and safe control of motor-reversing operations in compact applications. Its integrated construction saves space and improves overall durability, ideal for compact installations.
Adding to its accolades, the DC88-259 Albright 100A 12V DC - INT Monoblock Motor Reversing Contactor is recognized as one of the most popular thruster reversing contactors in the industry. This popularity stems not only from its robust construction and reliable performance but also from its adeptness at handling the specific demands of thruster applications in marine environments.
DC88-259 is a very Common Vessel Thruster Contactor
Thrusters, essential for maneuvering vessels in tight quarters or during docking procedures, require precise and reliable reversing controls to operate effectively. The DC88-259 excels in this role, offering quick and efficient directional changes of the thruster motors. Its ability to perform rapid make and break connections, combined with the high conductivity and durability of its double-breaking main contacts with silver-alloy tips, ensures that thrusters operate smoothly and responsively under the command of the vessel's control system.
The compact and integrated design of this model, thanks to its monoblock construction, makes it particularly suited to the constrained spaces often found in marine applications. This space efficiency does not come at the expense of safety or reliability; built-in fail-safe mechanisms ensure that the contactor operates within safe parameters, thus protecting both the equipment and its users.
Given these qualities, it's no surprise that the Albright DC88-series and its "bigbrother" DC182-series has become a go-to choice for professionals in the marine industry seeking dependable and efficient thruster reversing solutions. Its popularity is a testament to Albright's commitment to quality, innovation, and understanding the needs of its customers in diverse applications, reinforcing a status as a premier choice in the realm of motor-reversing solenoids.
Intermittent contactors by design are predominantly used for hydraulic functions on vehicles, they make and break quicker than continuous solenoids and are not recommended for prolonged contact periods
The main contact circuit, designed for motor reversing, has a built-in failsafe, so that if both coils are energised simultaneously the contact arrangement is open circuit. This version of the DC88 has M8 stud main terminals and flying lead coil connections. Mounting is via the integral bracket formed into the coil housing case. Mounting can be horizontal or vertical, when vertical the M8 contact studs should point upwards.
DC88-307T Albright SOLENOID SWITCH 24V Intermittent
*shown product image of the product is without the dust shields, actual product is fitted with dust shields fitted.
